QT8-15C Automatic Block Production Line
The QT8-15C pairs hydraulic vibration, PLC control, and automated handling to deliver up to 8,600 concrete blocks per hour with minimal labor.
Throughput
8,640 blocks/hr
Machine Power
35 KW
Automation
Full
See it in action
Experience the engineering excellence of the QT8-15C Automatic Block Production Line. High-performance output meets precision control in this detailed demonstration.
Click to load video
YouTube
Product overview
Engineered for mega infrastructure and housing programs, QT8-15C keeps throughput consistent via dual vibration tables, servo-driven stacking, and redundant safety sensors. It is our most deployed turnkey system across Bangladesh.
PLC + HMI centralized control
Auto pallet feeding & stacking
Hydraulic vibration bed
Adaptive mold recognition
Energy optimization profiles
24/7 remote diagnostics
2-year machine warranty - 5-year critical component warranty - On-site commissioning - Operator bootcamp
Key specifications
- Machine Size
- 4000 x 2300 x 2950 mm
- Vibration Force
- 70 - 80 KN
- Vibration Frequency
- 2800 - 4500 rpm
- Host Power
- 35 KW
- Total Project Power
- 115 KW
- Host Weight
- 7.5 T
- Pallet Size
- 1050 x 900 x 28 mm
- Recommended Area
- 5800 sft shed / 130 decimal land
| Format | Cycle | Per hour |
|---|---|---|
| Hollow 400x200x200 | 15 - 20 s | 1,920 - 1,440 blocks |
| Hollow 400x200x115 | 15 - 20 s | 3,360 - 2,520 blocks |
| Solid brick 240x115x70 | 15 - 20 s | 8,640 - 6,480 bricks |
| Paver 220x110x80 | 15 - 20 s | 6,720 - 5,040 units |
Applications
Large-scale construction suppliers
Government housing projects
Export-oriented block plants
